Introduction

Machine Learning (ML) pipelines streamline model development, training, and deployment by automating repetitive tasks. However, manually deploying ML models can be error-prone and time-consuming. Integrating Continuous Integration (CI) and Continuous Deployment (CD) ensures that updates are tested and deployed efficiently, improving reliability and scalability.

In this guide, we’ll build a complete ML pipeline from scratch, covering:

Understanding the problem
Data preprocessing
Model training and evaluation
Model deployment using Flask
Implementing CI/CD with automated testing
Deploying using Docker

Ready to lead the future? Start your AI/ML journey today!

In- depth knowledge and skill training
Hands on labs
Industry use cases

Enroll Now

Use Case: Predicting Iris Flower Species

To demonstrate an end-to-end ML pipeline, we’ll develop an ML model to classify iris flowers into three species based on petal and sepal dimensions.

Dataset Overview

We use the well-known Iris dataset, which consists of:

Features: Sepal length, Sepal width, Petal length, Petal width
Target Variable: Species (Setosa, Versicolor, Virginica)

ML Model Development

Setting Up the Environment

To ensure reproducibility, install the necessary dependencies:

pip install numpy pandas scikit-learn flask pytest requests

Data Preprocessing and Model Training

Data preprocessing is crucial in ML pipelines to clean and transform raw data before feeding it into a model. Here, we load the dataset, encode categorical values, split it into training and testing sets, train a RandomForest model, and evaluate its accuracy.

import numpy as np

import pandas as pd

from sklearn.model_selection import train_test_split

from sklearn.ensemble import RandomForestClassifier

from sklearn.metrics import accuracy_score

import joblib




# Load dataset

df=pd.read_csv('https://raw.githubusercontent.com/mwaskom/seaborn-data/master/iris.csv')




# Encode target variable

df['species'] = df['species'].astype('category').cat.codes




# Split data

X = df.drop(columns=['species'])

y = df['species']

X_train, X_test, y_train, y_test = train_test_split(X, y, test_size=0.2, random_state=42)




# Train model

model = RandomForestClassifier(n_estimators=100, random_state=42)

model.fit(X_train, y_train)




# Evaluate model

y_pred = model.predict(X_test)

print("Accuracy:", accuracy_score(y_test, y_pred))







# Save model

joblib.dump(model, 'iris_model.pkl')

import numpy as np

import pandas as pd

from sklearn.model_selection import train_test_split

from sklearn.ensemble import RandomForestClassifier

from sklearn.metrics import accuracy_score

import joblib

# Load dataset

df=pd.read_csv('https://raw.githubusercontent.com/mwaskom/seaborn-data/master/iris.csv')

# Encode target variable

df['species'] = df['species'].astype('category').cat.codes

# Split data

X = df.drop(columns=['species'])

y = df['species']

X_train, X_test, y_train, y_test = train_test_split(X, y, test_size=0.2, random_state=42)

# Train model

model = RandomForestClassifier(n_estimators=100, random_state=42)

model.fit(X_train, y_train)

# Evaluate model

y_pred = model.predict(X_test)

print("Accuracy:", accuracy_score(y_test, y_pred))

# Save model

joblib.dump(model, 'iris_model.pkl')

Expected Model Performance

An accuracy score is printed, indicating the model’s performance. Example output:

Accuracy: 0.9667

Model Deployment with Flask

Why Use Flask?

Flask is a lightweight Python framework for building web applications and APIs. We use it to serve our trained ML model as a REST API.

Creating the API Server

from flask import Flask, request, jsonify

import joblib

import numpy as np




app = Flask(__name__)




# Load model

model = joblib.load('iris_model.pkl')




@app.route('/predict', methods=['POST'])

def predict():

    data = request.get_json()

    features = np.array(data['features']).reshape(1, -1)

    prediction = model.predict(features)

    return jsonify({'prediction': int(prediction[0])})




if __name__ == '__main__':

    app.run(debug=True)

from flask import Flask, request, jsonify

import joblib

import numpy as np

app = Flask(__name__)

# Load model

model = joblib.load('iris_model.pkl')

@app.route('/predict', methods=['POST'])

def predict():

data = request.get_json()

features = np.array(data['features']).reshape(1, -1)

prediction = model.predict(features)

return jsonify({'prediction': int(prediction[0])})

if __name__ == '__main__':

app.run(debug=True)

Running the Server

python app.py

Testing the API

We can test the API using curl:

curl -X POST http://127.0.0.1:5000/predict -H "Content-Type: application/json" -d '{"features": [5.1, 3.5, 1.4, 0.2]}'

1	curl -X POST http://127.0.0.1:5000/predict -H "Content-Type: application/json" -d '{"features": [5.1, 3.5, 1.4, 0.2]}'

API Response

{“prediction”: 0}

Implementing CI/CD Pipeline

What is CI/CD?

Continuous Integration (CI) ensures that code changes are automatically tested before merging. Continuous Deployment (CD) ensures that successfully tested changes are automatically deployed. We implement this using GitHub Actions.

Setting Up CI with GitHub Actions

Create a .github/workflows/test.yml file:

name: CI Pipeline




on:

  push:

    branches:

      - main




jobs:

  test:

    runs-on: ubuntu-latest




    steps:

      - name: Checkout code

        uses: actions/checkout@v2



      - name: Set up Python

        uses: actions/setup-python@v2

        with:

          python-version: '3.8'



      - name: Install dependencies

        run: pip install -r requirements.txt



      - name: Run tests

        run: pytest

name: CI Pipeline

on:

push:

branches:

- main

jobs:

test:

runs-on: ubuntu-latest

steps:

- name: Checkout code

uses: actions/checkout@v2

- name: Set up Python

uses: actions/setup-python@v2

with:

python-version: '3.8'

- name: Install dependencies

run: pip install -r requirements.txt

- name: Run tests

run: pytest

Writing Unit Tests

Unit tests ensure that the API functions correctly.

import pytest

import json

from app import app




def test_prediction():

    tester = app.test_client()

    response = tester.post('/predict',

                           data=json.dumps({"features": [5.1, 3.5, 1.4, 0.2]}),

                           content_type='application/json')

    assert response.status_code == 200

    assert 'prediction' in response.get_json()

import pytest

import json

from app import app

def test_prediction():

tester = app.test_client()

response = tester.post('/predict',

data=json.dumps({"features": [5.1, 3.5, 1.4, 0.2]}),

content_type='application/json')

assert response.status_code == 200

assert 'prediction' in response.get_json()

Running Tests Locally

pytest test_app.py

Deployment with Docker

Why Use Docker?

Docker allows us to containerize our application, making it easy to deploy across different environments.

Creating a Dockerfile

FROM python:3.8

WORKDIR /app

COPY . /app

RUN pip install -r requirements.txt

CMD ["python", "app.py"]

FROM python:3.8

WORKDIR /app

COPY . /app

RUN pip install -r requirements.txt

CMD ["python", "app.py"]

Building and Running the Docker Container

docker build -t ml-api.

docker run -p 5000:5000 ml-api

docker build -t ml-api.

docker run -p 5000:5000 ml-api

Testing with Docker

curl -X POST http://127.0.0.1:5000/predict -H "Content-Type: application/json" -d '{"features": [5.1, 3.5, 1.4, 0.2]}'

1	curl -X POST http://127.0.0.1:5000/predict -H "Content-Type: application/json" -d '{"features": [5.1, 3.5, 1.4, 0.2]}'

Expected Output

{“prediction”: 0}

Conclusion

In this guide, we built an end-to-end ML pipeline that includes:

Model training and evaluation
API deployment using Flask
Automated testing with GitHub Actions
Containerization with Docker

With CI/CD automation, ML applications can be deployed seamlessly, ensuring efficiency and scalability.
