Disaster Recovery Plan with Azure Site Recovery

Voiced by Amazon Polly

Overview

Enterprises and cloud solutions teams, for the most part, recognize the importance of a disaster recovery solution. To define and select a disaster recovery plan, one of the first steps is to conduct a business impact analysis. This process helps identify applications that support critical business processes, assesses the business impact of an outage, and guides the creation of the best possible disaster recovery plan. After you’ve completed the analysis and identified the critical applications, you’ll need to create a disaster recovery strategy. Typically, this means:

  • Making continuous improvements in the failure points and identifying the talented workforce or administrators to manage the disaster recovery segment
  • Setting targets for recovery time objectives (RTOs) and recovery purpose objectives (RPOs)
  • Choosing the best product or service based on your requirements
  • Identifying all the necessary software and hardware resources
  • Testing the disaster recovery strategy regularly

Customized Cloud Solutions to Drive your Business Success

  • Cloud Migration
  • Devops
  • AIML & IoT
Know More

Planning Your Site Recovery

  • Establishing an ASR vault.
  • Introducing the ASR extension to every VM for it to connect to your ASR vault.
  • Replicating virtual machine discs to nearby temporary storage.
  • Construct virtual machines from duplicate discs in the secondary area.
  • Creating a replica of an original VM discs or storage account


Steps to Create a Vault for Recovery Services

You need to establish a vault for recovery services. So that the vault keeps the track of the replication in the process and shows how the process will take place. To prevent losing it with your other data if the azure region explodes, the vault is situated in the backup region.

To create the ASR vault:

Step 1: Type in Browser www.portal.azure.com and get logged into your Azure Portal.

Step 2: Type in the search box Recovery Service Vaults then the ASR Vault page will open.

Step2

Step 3: Click Create, provide details for creating recovery vaults and then click on Review + Create

Note: for the resource, the group creates a new resource group or provides an existing one.

After that provide a region where it will failover the site.

Step3

Steps to Enable Replication

After creating a vault, you should configure it by activating replication, or what Azure calls “Site Recovery.”

Step 1: Click Enable Site Recovery while still on your ASR vault page, as illustrated below

Step1ASR

You will see the replication options when your Recovery Services Vault opens.

Step 2: As shown below, click on Enable replication.

Step2ASR

Step 3: Now, make all the setup changes required to enable replication.

  • Source Location
  • Azure Virtual Machine Deployment Model
  • Source Subscription
  • Source Resource Group
  • Disaster Recovery between availability zones

Step3ASR

Step 4: Select the virtual machines you wish to replicate in the Source resource group provided above and click Next. After configuration of all inputs click next to enable replication.

Step4ASR

Several events take place after ASR starts the replication process:

  • ASR install the ASR extension on each VM to communicate with them.
  • The ASR extension authenticates with the Site Recovery vault.
  • A resource group with the suffix “- ASR” is created.
  • ASR creates managed discs for each VM and vNet, with names beginning with”-ASR.”
  • While the disc writes are being transferred to a local storage account, which serves as a dedicated cache in the source region, the vault starts duplicating the VMs. These writes are handled before being forwarded to the location you’ve chosen for failover.
  • The vault processes local storage data and sends it to an ASR-created storage account or managed discs in the destination region.
  • Every five minutes, ASR generates crash-consistent recovery points. Only the data present on the disc now of the snapshot is included in a crash-consistent snapshot. Contrary to an app-consistent snapshot, it excludes all data from memory.

Checking Replication Status:

In the dashboard navigate to the recovery services vault it may take some time to deploy after that you will see your resources marked as healthy and you can see the architecture.

CRS

CRS2

Conclusion

As reported by Gartner, a strength of the Azure Site Recovery tool is that “Microsoft has high success rates and speed of failover, with over 90% of ASR failovers completed in 10 minutes and 99.9% completed within 30 minutes

Get your new hires billable within 1-60 days. Experience our Capability Development Framework today.

  • Cloud Training
  • Customized Training
  • Experiential Learning
Read More

About CloudThat

CloudThat is a leading provider of Cloud Training and Consulting services with a global presence in India, the USA, Asia, Europe, and Africa. Specializing in AWS, Microsoft Azure, GCP, VMware, Databricks, and more, the company serves mid-market and enterprise clients, offering comprehensive expertise in Cloud Migration, Data Platforms, DevOps, IoT, AI/ML, and more.

CloudThat is the first Indian Company to win the prestigious Microsoft Partner 2024 Award and is recognized as a top-tier partner with AWS and Microsoft, including the prestigious ‘Think Big’ partner award from AWS and the Microsoft Superstars FY 2023 award in Asia & India. Having trained 850k+ professionals in 600+ cloud certifications and completed 500+ consulting projects globally, CloudThat is an official AWS Advanced Consulting Partner, Microsoft Gold Partner, AWS Training PartnerAWS Migration PartnerAWS Data and Analytics PartnerAWS DevOps Competency PartnerAWS GenAI Competency PartnerAmazon QuickSight Service Delivery PartnerAmazon EKS Service Delivery Partner AWS Microsoft Workload PartnersAmazon EC2 Service Delivery PartnerAmazon ECS Service Delivery PartnerAWS Glue Service Delivery PartnerAmazon Redshift Service Delivery PartnerAWS Control Tower Service Delivery PartnerAWS WAF Service Delivery PartnerAmazon CloudFront Service Delivery PartnerAmazon OpenSearch Service Delivery PartnerAWS DMS Service Delivery PartnerAWS Systems Manager Service Delivery PartnerAmazon RDS Service Delivery PartnerAWS CloudFormation Service Delivery PartnerAWS ConfigAmazon EMR and many more.

FAQs

1. What does Site Recovery do?

ANS: – By managing and automating the replication of Azure VMs between regions, on-premises virtual machines and physical servers to Azure, and on-premises computers to a backup facility, Site Recovery supports your business continuity and disaster recovery (BCDR).

2. Can I protect a virtual machine that has a Docker disk?

ANS: – No, Docker workloads on virtual machines are not backed by Azure Site Recovery. Exclude the discs that have Docker installed on them to protect these virtual machines with site recovery.

3. How can we migrate/protect software which requires a persistent MAC address on the virtual machine?

ANS: – Because Azure does not enable persistent MAC addresses, MAC-based license models cannot be used for both on-premises to Azure migration and disaster recovery.
